Relogger

This application, as illustrated in the Figure below, classifies descriptions into categorical classes (referenced data) within Geoscience ANALYST. The user must pre-define the categorical classes with descriptive names. Subsequently, the application matches each description with the class that has the highest likelihood. The output classification integrates seamlessly as referenced data in Geoscience ANALYST, immediately linked to the corresponding data object. Users can then easily visualize and refine the classification as necessary.

../_images/relogger_principle.png

Interface

You can run the application using the interface depicted in Figure below.

../_images/relogger_uijson.png

The interface contains the following parameters:

  • Drillhole Data : The drillhole group and the associated text data to relog.

  • Object: The object containing the text data to relog.

  • Data: The text data to relog.

  • New Classes: The classes use for the relogging. They must be separated with commas + space (,). The name of the classes must be descriptive as the relogging is based on their meaning.

  • LL Model: The language model to use for relogging. The available models are listed in the Models Available table.

  • OK: Clicking “OK” runs the application with the specified parameters.

The application opens a console displaying the progress of the relogging. Upon completion, the new classification is made available as a referenced Data within the Geoscience ANALYST project.

Results

The results can be found in Geoscience ANALYST, as illustrated in the figure below. A Referenced Data entry is created under the object selected in the application (DrillholeData or Object in the Interface).

../_images/result_relogger.png
